Water Depth Measuring Meter
  • Water Depth Measuring Meter India

WATER DEPTH MEASURING METER (ACM-52308)

  • Accurate water level measurements
  • Obtain measurements in seconds
  • Avoid cross-contamination
  • No equipment to clean

Works in cased steel or PVC-capped wells, partially cased rock wells, crooked wells, and wells with pipes, wiring, and operating pumps.

  • SPECIFICATIONS
  • Performance Measurement Range: Normal 10-500' or Deep up to 1200'
  • Readout Accuracy: +0.1'
  • Measurement Accuracy: + 0.2% of reading*
  • Operating Temperature: 30-140° F
  • Power: 8 AA dry cell batteries
  • Dimensions:(excluding sonic measuring duct) Length: 7"; Height: 4"; Width: 5
  • Sonic Measuring Duct Diameter: 5/8"
  • Hole diameter must be at least large enough for 1/2 pipe thread.
  • Sonic Measuring Duct Length: 2"
