WATER DEPTH MEASURING METER (ACM-52308)

Accurate water level measurements
Obtain measurements in seconds
Avoid cross-contamination
No equipment to clean

Works in cased steel or PVC-capped wells, partially cased rock wells, crooked wells, and wells with pipes, wiring, and operating pumps.

SPECIFICATIONS

Performance Measurement Range: Normal 10-500' or Deep up to 1200'
Readout Accuracy: +0.1'
Measurement Accuracy: + 0.2% of reading*
Operating Temperature: 30-140° F
Power: 8 AA dry cell batteries
Dimensions:(excluding sonic measuring duct) Length: 7"; Height: 4"; Width: 5
Sonic Measuring Duct Diameter: 5/8"
Hole diameter must be at least large enough for 1/2 pipe thread.
Sonic Measuring Duct Length: 2"
